Mechanical Specifications

• Dimensions: 483mm (width) × 44mm (height) × 383mm (depth)

• Weight: 7.70 kg

• Mounting Options: 19" rack 1U

• Mounting Direction: Primary horizontal, secondary vertical

• Cooling Method: Self - contained

• Product Color: Gray (NCS S 1002 - B)

Environmental Specifications

• Temperature for Normal Operation: 0°C (min) to 55°C (max)

• Certifications: Encapsulation class IP20; complies with safety standards such as IEC/EN 62368 - 1, UL 62368 - 1, and CAN/CSA - C22.2 No. 62368 - 1

• Regulatory Approvals: CE, CB, CET, LUS; complies with NEBS (GR - 63, GR - 1089, GR - 3108)

• EMC Immunity: Meets ETSI EN 301 489 - 1, TS 37.113, and ETSI EN 301 489 - 50 standards

• EMC Emission: Complies with ETSI EN 301 489 - 1, ETSI EN 301 489 - 50, ETSI EN 301 908 - 1, FCC Part 15, and ICES - 003 TS 37.113 standards; emission class B

Electrical Specifications

• Power Supply: - 48V DC, DC - I and DC - C types, with dual redundant power input connections (using OR - ing diode), 25A CB rating, 25A fuse rating

• Ethernet Ports:

  • 1 RJ45 port for 1Gbps Ethernet (electrical)

  • 4 QSFP28/SFP28 ports for 1G/10G/25G Ethernet

• Radio Interface Ports: 12 SFP28 ports for CPRI/ECPRI (supporting various data rates such as 2.4G, 4.9G, 9.8G, 10.1G, 24.3G, 10.3G, 25G)

• Other Ports:

  • 1 RJ45 port for local maintenance terminal (LMT)

  • 2 RJ45 ports for external alarm (EA)
